Dave Hill Designs Europa 1

Eenkanaals microfoon voorversterker boordevol functies

Prijs op
aanvraag

Voeg dit product toe aan uw offerte

In offerte

Vragen? Betere prijs gezien?

Bel 0512 - 340457 of neem contact op!

Product omschrijving

Dave Hill Designs Euopa 1

A feature packed Europa One

The Europa I from Dave Hill Designs represents a totally unique design concept in microphone pre-amplifier technology.

Included are the standard functions such as phase, phantom power and an instrument input. The microphone input has 3 input impedance choices which are 2.2K ohms for normal microphone operation, 300 ohms and a Hi-z choice for different microphone sounds.  The instrument input has an impedance of 1.2 Meg ohms which is ideal for guitars.  The gain over all is adjustable in 1db steps from 0 to 66db on the mic input and 0 to 30 dB on the instrument input. Gain is displayed on a 2-digit led display. The low cut filter which is a 3 pole, 18db per octave has 8 frequencies 148 Hz, 130 Hz, 117 Hz, 100 Hz, 81 Hz, 63 Hz, 48 Hz, 33 Hz, and off.

Unique to the Europa pre-amp are 3 controls for changing the color of the pre-amp. The first control is a SPEED which changes how fast the pre-amp can respond. The control goes from 0 to 8 with 8 being the fastest rate, and 0 being very drastic. The even harmonic control provides 9 levels of color from 0 to 8, and the odd harmonic control which also has 9 levels color with the 0 setting being the cleanest in both cases. These three controls are a series analog process so that the even harmonic control affects the sound of the speed control and the odd harmonic control affects the sound of both the speed and even harmonic controls

All the controls; gain, speed, even harmonic, the odd harmonic controls are stepped which makes it easy to recall settings.

The level meter has a 0 VU reference point of (+4dbu) with one dB steps going to +20 dB above 0VU and to -25 dB below 0 VU with the steps being larger than 1 dB below -16 db.

The maximum output level is +24 dBu balanced with the maximum balanced input level of +24 dBu at 0 dB of gain.  This allows the Europa 1 pre-amp to be used in a mix environment for coloring.

SPECIFICATIONS

  • Maximum input: +24 dBu balanced, +16 dBu unbalanced
  • Maximum output: +24 dBu balanced
  • High-pass Filter: 3 pole, 18 dB per octave, 8 frequencies 148 Hz, 130 Hz, 17 Hz, 100 Hz, 81 Hz, 63 Hz, 48 Hz, 33 Hz
  • Gain: 0 to 66 dB, 1 steps
  • Gain Instrument Input: 0 to 30 dB, 1 dB steps
  • Mic Impedance:
    200K, 2.2k, 300 ohms
    at gains < 13db the Hi-z position will be around 15K ohms



  • Instrument Impedance: 1.2 Meg ohm
  • Noise: EIN -127.5 dBu, 20KHz Bw
  • Power:
    25 watts at 115 or 230 volts, 50 or 60 Hz.
    Fuse size is GMD .315A for 115 volts; GMD .15A for 230 volts
    for 100 - 120 volts set to 115v
    for 220 - 240 volts set to 230v
  • Shipping Weight: 15 lbs. (6.7 kg)
  • Depth Behind Panel: 8.625 inches plus user input/output connectors
