Trident Audio Developments Trident 68 Console

Trident Audio Developments Trident 68 Console

Trident 68 Console – 16 Channel
Trident 68 Console – 24 Channel

Building from over 50 years of design experience, the Trident 68 analog consoles have been developed to deliver the core feature set most often needed for analog recording. The 68’s are Split/lnline consoles with individual channels in 8-way panels. Using an 8 subgroup configuration and incorporating 6 Aux sends, its routing options are vast and simple to use. Connections are fast and easy with DB-25’s throughout the board and XLR’s for Master and Main outputs. With a flexible yet powerful 3 band EQ at its core, including selectable channel inserts and monolithic preamps driving the inputs, the Trident 68 consoles offer a wide array of summing and mixing options. The sonic quality and compact footprint of the 68’s is able to meet any demand.

Modularity Throughout

The 68’s by design are manufactured to be a more cost effective variant of the fully modular 78’s. Incorporating a similar chassis design and the LED meter bridge, the 68’s have a rugged and proven core. Using a simi-modular design the 68’s are able to effectively reduce their overall costs without a significant sacrifice to serviceability.

• All input channels are individual boards, faders included, each in a 8 channel pack.
• Subgroups are individual boards, faders included, each in a 8 channel pack.
• Master Channel is an individual channel separated from all others.
